| LCD Size |
0.59” with MLA |
| Native Resolution |
WXGA |
| Brightness (White and Colour) |
WHITE LIGHT OUTPUT (NORMAL/ECO) EB-485Wi: 3,100lm / 1,800lm |
| COLOUR LIGHT OUTPUT (NORMAL/ECO) EB-485Wi: 3,100lm (Colour mode: Dynamic, Zoom: Wide) |
| *Colour brightness (colour light output) and white brightness (white light output) will vary depending on usage conditions. Colour light output measured in accordance with IDMS 15.4; white light output measured in accordance with ISO 21118. |
| Contrast Ratio |
3000:1 (Auto Iris: On) |
| Projection Lens |
TYPE: No Optical Zoom / Focus (Manual) |
| F-NUMBER: 1.80 |
| FOCAL LENGTH: 3.71mm |
| ZOOM RATIO: 1.0 - 1.35 (Digital Zoom) |
| Screen Size (Projection Distance) |
60” - 100” [0.348m - 0.597m] 74.3” screen 0.438 m |
| Throw Ratio |
0.27 - 0.37 (Wide - Tele) |
| Lamp Type |
EB-485W: 215W UHE |
| Lamp Life |
NORMAL/ECO: 3,000 hours / 4,000 hours |
| *Lamp life will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time. |
| Keystone Correction |
VERTICAL/ HORIZONTAL: ±5° |
| Input Interface |
D-SUB 15PIN: 2 (Blue) |
| COMPONENT: D-sub 15pin (Blue molding) x 2 (in common with Analog RGB connector) |
| COMPOSITE: RCA (Yellow) x 1 |
| S-VIDEO: 1 Mini DIN |
| Output Interface |
D-SUB 15PIN: 1 (Black) |
| HDMI |
1 |
| USB Interface |
USB TYPE A: USB Type A x 1 (USB memory/ELPDC06 document camera) |
| USB TYPE B: USB Type B x 1 (USB Display, Mouse, K/B, Interactive) |
| Control Interface |
RS-232C: D-sub 9pin x 1 |
| USB: USB Type B x 1 (USB Display, Mouse, K/B, Interactive) |
| Network Interface |
WIRED LAN: RJ45 x 1 / 100Mbps |
| WIRELESS: Optional Accessory (ELPAP07) |
| Sound Output |
16W Monaural |
| Operating Temperature |
5°C - 35°C <41°F - 95°F> (20% - 80% humidity, unfrozen) |
| Dimensions (Including Lens and Feet) |
W x H x D: 367mm x 143mm x 375mm (14.45” x 5.63” x 14.76”) |
| Weight |
Approx. 5.4kg / 11.9lbs |
| Fan Noise |
NORMAL / ECO 35dB / 28dB |
